TUBE FLEX
Tube Flex model has a 160 chuck size and a power range of 3000W to 6000W. It can support tube feeding up to 12000mm (472″) and workpiece lengths up to 9000mm (354″). The machine weighs 3.5T and has a maximum idle speed of 8000 mm/s
The machine has several advantages, such as:
- The ability to achieve zero tail material cutting with free switching of cutting areas for long materials.
- A unique bevel cutting method with a groove, which simplifies pipe splicing and welding.
- A high-precision servo chuck that offers better clamping accuracy, improved dust resistance, and a longer service life. This chuck also prevents thin-walled tubes from deforming and allows for the cutting of special-shaped tubes.
MACHINE SPECS
| Model Number | A160T |
|---|---|
| Tube Size (Maximum Outside Diameter) | Tube Size (Maximum Outside Diameter) Round tube Ø 13- Ø160; Square tube 13×13-160×160; Other tube |
| Types: | Maximum outer diameter ≤160 (manual) |
| Loading Capacity | 157”-275” |
| Repeated Positioning | +0.03mm (0.001”) |
| Maximum speed | 850°/s |
| Maximum Idle | Speed 8000 mm/s |
| Chuck Load | 200KG (440 lb) |
| Machine Weight | 3.5T |
| Machine size | 439” x 111” x 79” H |
